Denago Cruiser Model 1 Top-tube eBike

write a review

Regular price $1,099.00
Regular price $1,099.00 Sale price $1,099.00
Sale Sold out
Size: One Size
Color: Black
Questions? Let Us Help
The perfect eBike for your next beach path adventure or pub crawl. Cruiser 1 offers classic, stealthy styling with a black frame and components. Upright riding position makes it fun for everyone to ride.

  • 5 levels of pedal assist plus throttle, at your fingertips

    Pedal assist boosts you to 8, 12, 16, 18, or 20 MPH, or throttle without pedaling at up to 20 MPH.

  • Sleek, hidden battery - looks like a regular bike!

    The 36V, 11A (396Wh) Lithium-Ion battery is color-matched to the frame and built with premium LG cells. It locks to the frame for security with the included key.

  • Digital display

    See your speed and battery charge at a glance and control your pedal assist level on the easy-to-operate digital display.

  • Focused on comfort

    Riding is supposed to be fun! We used ergonomic grips, a high-rise swept handlebar, and padded saddle that allow you to ride without hunching over.

  • Twist throttle

    Familiar and easy for riders of all skill levels to operate. Up to 20 MPH without pedaling.

  • Shengyi 350 Watt hub motor

    36V hub motor provides just the right amount of boost to suit your terrain and riding conditions.

1 of 6

Collapsible content

See Full eBike Features

Top Speed:
20 MPH on pedal assist, 20 MPH on throttle (Class II eBike)

Motor:
Shengyi 350W, 36V rear hub motor

Battery:
36V, 11A (396Wh) Lithium-ion, built with LG 18650 cells

Sensors:
Cadence, Speed

Throttle:
Twist throttle, left side

Display:
Denago digital display with speed, trip distance, and odometer functions; displays battery charge level and allows selection of pedal assist level

Charger:
Multi-voltage 110-240V, 3A Fast Charger with USA plug

Safety Data Sheets (SDS):
Denago safety data sheets are available upon request via email.

  • Classic style

    Beautiful frame features clean lines that evoke the classic cruisers we grew up with. Traditional top tube frame design.

  • Includes fenders

    Each Cruiser 1 eBike includes stylish fenders that match the frame and fork color.

  • Powerful disc brakes

    Mechanical disc brakes with oversized rotors and motor cut-off switches for safety.

  • High-rise cruiser handlebar

    High-rise, backswept handlebar puts you in an upright, comfortable riding position so you can look around and enjoy the scenery.

  • Twist shifter with optical gear display

    Microshift twist shifter is simple to operate, even for beginners. The optical display shows your gear at a glance.

  • Sturdy kickstand

    Makes parking a snap at home, the beach, or your favorite coffee shop.

  • Built-in chainguard

    Keeps grit and grime off your pants leg.

  • Mounting points for front and rear racks

    Easily add an optional front or rear rack to your Cruiser with heavy-duty mounting points built in to the frame.

1 of 8

Collapsible content

See Full Component Specifications

FRAME AND FORK

Frame:
6061-T6 Aluminum Alloy, Top tube style

Fork:
Rigid, 6061-T6 Aluminum Alloy

Kickstand:
included

DRIVETRAIN

Pedals:
Platform, non-slip surface, 9/16” with reflectors

Crankset:
170mm, 42 teeth

Bottom Bracket:
Sealed, square taper, English thread

Rear Derailleur:
Microshift RD-M21S

Freewheel:
Shimano Tourney, 7 speed, 14-28 teeth

Shifter:
Microshift 7 speed twist shifter with optical gear display

Chain:
KMC Z-Series, 3/32”

COCKPIT

Handlebar:
High-rise chrome plated steel, 690mm width, 25.4mm diameter

Handlebar Bell:
included

Grips:
Black rubber, lock-on style

Stem:
90mm extension, 25.4mm clamp, height adjustable

Headset:
1 ⅛”, sealed, threadless

Saddle:
Black, padded with memory foam

Seatpost:
Zoom aluminum alloy, 30.4mm diameter, 400mm length

Seatpost Clamp:
Zoom, quick release

BRAKES

Levers:
Jak mechanical disc brake with motor cut-off

Calipers:
Jak mechanical disc brake

Rotors:
180mm, 6 bolt type

WHEELS

Tires:
27.5" x 2.3" cruiser tires, eBike rated, puncture resistant with safety reflective strip

Tubes:
27.5" x 2.3", schrader valve

Rims:
Aluminum Alloy, 36 holes, 27.5"

Hubs:
Front - nutted, 36 holes, disc brake
Rear - Shengyi, nutted 36 holes, disc brake

Spokes:
Front - 36, 13 gauge spokes
Rear - 36, 12 gauge spokes

Nipples:
Brass

WEIGHT AND PAYLOAD

Complete eBike with battery:
56 lbs

Maximum rider weight:
300 lbs

Maximum cargo capacity:
55 lbs on the optional seatstay-mounted rear rack
20 lbs on the optional headtube-mounted front rack

WHAT'S IN THE BOX

Complete eBike
Keys
Lithium-Ion battery
3 Amp fast charger
Quickstart guide
Wheel reflectors
Assembly Tools (pedal wrench, multi-tool)

COVID-19 has created specific challenges in the bicycle industry, especially around the availability of the components required to manufacture eBikes. As a result, we reserve the right to make substitutions of equivalent components of equal or better value to ensure we can consistently deliver our eBikes in a timely fashion. Thanks for understanding!

  • Tam is 5'2" tall

    Shown riding Cruiser Model 1 Step-thru, one size

  • Asma is 5'3" tall

    Shown riding Cruiser Model 1 Step-thru, one size

  • Lisa is 5'6" tall

    Shown riding Cruiser Model 1 Step-thru, one size

  • Johnathan is 6'1" tall

    Shown riding Cruiser Model 1 Step-thru, one size

1 of 4

Collapsible content

Denago's size and fit recommendations

One size fits most adults 5'4" - 6'3"

  • UPS logo

    Always free shipping

    Free standard shipping is available on all eBikes offered at Bike.com.

  • Fast delivery of your new eBike

    Free standard shipping arrives anywhere in the 48 continental United States in just 1-5 business days.

  • Pay over time with Affirm

    Choose Affirm during checkout and buy your new eBike with easy monthly payments.

    Financing options
  • Do it yourself

    Assembly tools and instructions included with every eBike. Get free help from the Bike.com experts anytime.

  • Beeline Connect logo

    Get help from a local bike shop via Beeline Connect

    Choose a local bike shop to assemble and tune your new eBike. Additional charge applies. Learn more.

  • Order 2 and get free ready to ride delivery

    Order 2 eBikes and we'll build and tune them, then deliver them to you ready to ride. Learn more.

1 of 3

Documents for the Denago Fat Tire Step-thru eBike

DOWNLOADS

Geometry Chart

Denago Cruiser 1 Top Tube eBike Geometry
Last updated: Feb 10, 2023. (JPG)

Quick Start Guide

Denago Cruiser 1 eBike Quick Start Guide
Last updated: Feb 10, 2023. (PDF)

Owner's Manual

Denago Cruiser 1 eBike Owner's Manual
Last updated: Feb 10, 2023 (PDF)

Display Instructions

Denago Cruiser KM3209 Display Instructions
Last updated Feb 10, 2023 (PDF)
