Denago City Model 2 Top Tube eBikewrite a review
Denago City Model 2 Step-thru eBike Features
Up to 28 MPH on pedal assist and 20 MPH on throttle
This Class III eBike features both pedal assist and throttle models. Dial in your desired level of pedal assist on the handlebar remote.
Stealthy, integrated battery
652.8 Wh (48V, 13.6A) battery is integrated into the down tube for a stealthy look, making it less obvious you're riding an eBike. Includes 3 Amp fast charger, you can charge with the battery on, or off the bike.
40+ mile range
Real-world range testing shows most riders will get more than 40 miles on a single charge when using pedal assist, and 20 miles on throttle alone.
Monitor your speed, distance, battery charge, and other data on the high-resolution display. Set an optional PIN code for additional security.
See Full eBike Features
28 MPH on pedal assist, 20 MPH on throttle (Class III eBike)
Shengyi rear hub, 48V, 500W
Lithium-ion, 4V, 13.6A (652.8Wh) built with LG 18650 cells
Thumb throttle, left side
Denago high-resolution LCD with speed, pedal assist level, trip distance, odometer, trip time, battery charge level, and walk mode functions.
Multi-voltage 110-240V, 3A Fast Charger with USA plug
Safety Data Sheets (SDS):
Denago safety data sheets are available upon request via email.
Versatile 2.6" tires
Tackle more varied terrain with wider 2.6" tires that absorb bumps and rough pavement. They're eBike-rated and features anti-puncture technology, plus reflective sidewalls for safety.
Upgrade to a suspension fork later, without affecting the geometry of your eBike. Future-proof design in case your needs change.
Powerful hydraulic disc brakes
City Model 2 uses hydraulic disc brakes with oversized rotors for more braking power.
8 speed drivetrain with OGD
With an 11-32 tooth cassette, you'll have a wide range of gears, for everything from hills to headwinds. Optical Gear Display shows your chosen gear at a glance.
Kickstand makes parking a snap at your home, office, or vacation spot.
Padded saddle with lift handle
Comfortable, wide, padded saddle includes a lift handle to help you carry your eBike up stairs or load onto a car rack.
See Full Component Specifications
FRAME AND FORK
6061-T6 Aluminum Alloy, Top tube style
Rigid, suspension-corrected length
Platform, aluminum alloy, 9/16” with reflectors
Aluminum alloy, 170mm, 42 tooth chainring
Sealed, square taper, English thread
Microshift M26, 8 speed
8 speed, 11-32 teeth
Microshift 8 speed
KMC Z-Series, 3/32”
Zoom aluminum alloy, 31.8mm diameter, 660mm long
Black rubber, lock-on style
Zoom aluminum alloy, 31.8mm clamp, 1 ⅛” threadless, adjustable angle
1 ⅛”, sealed, threadless
Comfort with lift handle
Zoom aluminum alloy, 30.4mm diameter, 300mm length
Zoom, quick release
Hydraulic disc brake with motor cut-off
Hydraulic disc brake
180mm, 6 bolt type
27.5" x 2.6", puncture protection with safety reflective stripe
27.5" x 2.6", schrader valve
Aluminum Alloy, 36 holes, 27.5"
Front - nutted, 36 holes, disc brake
Rear - Shengyi, nutted 36 holes, disc brake
Front - 36, 13 gauge spokes
Rear - 36, 13 gauge spokes
WEIGHT AND PAYLOAD
Complete eBike with battery:
Maximum rider weight:
Maximum cargo capacity:
55 lbs on the optional seatstay-mounted rear rack
WHAT'S IN THE BOX
3 Amp fast charger
Assembly Tools (pedal wrench, multi-tool)
COVID-19 has created specific challenges in the bicycle industry, especially around the availability of the components required to manufacture eBikes. As a result, we reserve the right to make substitutions of equivalent components of equal or better value to ensure we can consistently deliver our eBikes in a timely fashion. Thanks for understanding!
Upgrades from City Model 1
- Fully-integrated vs. semi-integrated battery
- 8 speed drivetrain vs. 7 speed drivetrain
- Suspension-corrected fork
- Wider (2.6") tires vs. 2.3" tires
HOW IT FITS
Sam is 6' tall
Shown riding City Model 2 Step-thru, size L/XL
Lakana is 5'7" tall
Shown riding City Model 2 Top Tube, size S/M
Dustin is 6'1" tall
Shown riding City Model 2 Step-thru, size L/XL
Full geometry chart and dimensions
Denago's size and fit recommendations
Size S/M for riders 5'0" - 5'9"
Size L/XL for riders 5'9" - 6'4"
SHIPPING, FINANCING, AND SAFETY
Always free shipping
Free standard shipping is available on all eBikes offered at Bike.com.
Fast delivery of your new eBike
Free standard shipping arrives anywhere in the 48 continental United States in just 1-5 business days.
Free subscription to Flare PremiumLearn more about Flare
We've partnered with Flare to provide a free 1 year subscription to their Premium safety and tracking app with every eBike sold.
Do it yourself
Assembly tools and instructions included with every eBike. Get free help from the Bike.com experts anytime.
Get help from a local bike shop via Beeline Connect
Choose a local bike shop to assemble and tune your new eBike. Additional charge applies. Learn more.
Order 2 and get free ready to ride delivery
Order 2 eBikes and we'll build and tune them, then deliver them to you ready to ride. Learn more.
Denago City Model 2 Top Tube geometry chart
Last updated: Feb 8, 202 (JPG)
Quick Start Guide
Denago City Model 2 eBike Quick Start Guide
Last updated: Feb 8, 2023. (PDF)
Denago City Model 2 eBike Owner's Manual
Last updated: Feb 8, 2023 (PDF)
Denago City Model 2 eBike K5242 Display Instructions
Last updated Feb 8, 2023 (PDF)
